PressureMAT User Guide

Revision 1

Page 14/29

Input Programming

At this screen the UP/DOWN arrows are used to select what function to program. Press the

SELECT/PROG button to program the function. The setting or digit of a setting that can be

changed with the UP/DOWN arrows blinks. If there is more than one digit in a setting, use the

RIGHT/LEFT arrows to scroll within the possible digit locations within a setting. Pressing the

SELECT/PROG button will confirm a change- UNTIL THIS IS DONE, A SETTING

CHANGE IS NOT CONFIRMED. Pressing the HOME or BACK button before confirming a

setting change with the SELECT/PROG button will escape from that program menu without

saving changes made before confirming the entry.

Channel X Input Programming

> Low Alarm 0.00 bar

High Alarm 0.00 bar

Alarm Valid 000 sec

Comm Port Off

Time Alarm 0000 hrs

[SELECT] home display value

After 30 seconds of inactivity in the program menu, the selected setting to change stops

blinking and the value before the setting was selected is restored.

Changing the Low Pressure Alarm Point- Press the SELECT/PROG with Low Alarm selected

Use the RIGHT ARROW button on the keypad until you get to the digit that you want to

change. Use the DOWN ARROW/UP ARROW buttons on the keypad to change the values.

Note the location of the minus sign is the furthest to the left and the easiest way to access this

is by scrolling to the right until the cursor appears on the far left. To change a digit from a

numerical value to zero, change the value to a zero. When the correct value has been selected,

press the SELECT/PROG button and the value will be confirmed. To escape from this menu

without changing the value, press the BACK button and the main channel menu will appear.

Changing the High Pressure Alarm Point- Press the SELECT/PROG with High Alarm selected
