PressureMAT User Guide
Revision 1
Page 16/29
Output Programming
At this screen the UP/DOWN arrows are used to select what function to program. The only
function active is the Name. The Port Type can be selected and changed but no changes will
be confirmed and will revert to the default setting.
Channel X Output Programming
Port Type Out 0-20mA
> Name
Press the SELECT/PROG button to program a name that appears on the line under the line
where the pressure value is displayed for the selected channel (if Name is selected on the
Output Viewing menu). A wide range of alpha-numeric digits can be selected. Use the
RIGHT ARROW button on the keypad until you get to the digit that you want to change. Use
the DOWN ARROW/UP ARROW buttons on the keypad to change the values. The “*”
character indicates a space. Pressing the SELECT/PROG button will confirm a change-
UNTIL THIS IS DONE, A SETTING CHANGE IS NOT CONFIRMED. Pressing the HOME
or BACK button before confirming a setting change with the SELECT/PROG button will
escape from that program menu without saving changes made before confirming the entry.
