PressureMAT User Guide
Revision 1
Page 18/29
Alarm Latch
If turned on, alarm conditions will remain after an alarm state occurred but is no longer
present until the STOP button is pressed
Backlight
Can be set to High, Medium or Low
Audio Beep
Can be turned Off.
Keypad Secure
If turned On, the function to zero the sensor with the left arrow is disabled.
Communications
Displays setting not used in the unit at the present time. DO NOT CHANGE SETTINGS
Date and Time
If SELECT/PROG button pressed, the following sub-menu appears:
DATE and TIME
> Date-Time DDMMMYY HH:MM:SS
Next Report DDMMMYY HH:MM:SS
Report Start DDMMMYY HH:MM:SS
Report Rate 000 hrs
Daylight Save Off
This menu is used mainly for controlling data output to a PC.
Note: See Appendix C on Data Collection to a PC
At this screen the UP/DOWN arrows are used to select the setting.
Date-Time
Used to set the current time. Use the RIGHT/LEFT ARROW button on the keypad
until you get to the digit that you want to change. Use the DOWN ARROW/UP
ARROW buttons on the keypad to change the values. To change a digit from a
numerical value to zero, change the value to a zero. When the correct value has been
selected, press the SELECT/PROG button and the value will be confirmed. To escape
from this menu without changing the value, press the BACK button and the main
channel menu will appear.
