Pennsylvania 7600E - Remote Serial Display

8
Remote Serial Display (RSD) Option
In RSD mode the instrument can be set to work with another unit as a “remote” either as the
main or the slave unit. Communication is pre-set for channel two only on both units.
(RS232, 9600, 8, none)
When in remote mode, re-access to the following selections requires using the internal “cal”
switch.
Remote unit can have full or partial control of the main unit. Devices are available to replace
the cable for wireless communication.
40
rd.OF,
rd.En,
rd.re
rd.En : Selects Indicator as Remote Display (RSD)
rd.re : Allows indicator to operate w/RSD
41 En.On Allow remote keypad operation
42 Zr.On Enable/Disable zero key
43 tr.On Enable/Disable tare key
44 Un.On Enable/Disable unit key
45 Print function with parameter “11” see below
46 Fn.On Enable/Disable all other functions
11.P1.xx 45.Pr.xx RSD Serial Port 1 RSD Print Key
off off Disabled Disabled
off on Disabled Sends print cmd to weigh meter
co off Sends co serial Disabled
co on Sends co serial Sends print cmd to weigh meter
dE off Disabled Disabled
dE on See right…..
Outputs demand format from
RSD serial port 1
