13
Tractor Requirements
EQUIPMENT MATCHING
The PENTA TMR Cutter-Mixer-Feeder trailer model is designed to be used with Agricultural
tractors. To ensure a good performance, the following recommendations regarding minimum
equipment size and horse-power should be met.
A loaded machine may weigh as much as 10,000 kg, or 22,000 lbs. An operator must use his own
discretion when determining whether the tractor attached is suitable for the terrain. Using a
small tractor on a heavy piece of machinery can cause severe injury or death if the operator loses
control of the machinery.
Never leave the mixer parked full. Staring up a mixer that has been stopped for more than ½ an
hour can greatly increase the start up horse power. And damage the drive train.
Mixer Series Horsepower
3030 40-70HP
4130 50-80HP
5030 50-80HP
5930 50-120HP
4430 60-90HP
6730 80-130HP
8030 130-160HP
9630 135-170HP
1130 140 -180HP
1430 150-200HP
1030 90-180HP
1730 200-250HP
