69
Compool/EasyTouch Pool and Spa Control System Upgrade Installation and User’s Guide
Compool power center (without breaker sub-panel)
Control panel
retaining screw
Control panel upper
hinge
Control panel lower
hinge
Control panel/plate
Compool Power Center upgraded with Compool/EasyTouch Control Panel
F
VALVES
HEATER SOLAR
FILTER
PUMP
MODE
MODES OF OPERATION
Auto:
Indoor control panel and other remote devices operate system.
Service: Service buttons on this panel operate system.
Other remote devices are disabled.
Time Out: Service buttons on this panel operate equipment for
three hours, then settings return to Auto mode.
V
Pool
Spa
Fill (Spillway)
Drain
1
2
3
4
5
6
7
MENU SELECT
Reset
Upgrade
AUX 1
AUX 2
AUX 3
AUX 4
AUX 5
AUX 6
AUX 7
AUTO HEATER
SPA 95 F / 100 F
AIR 70 F
MON 09:30 AM
Control panel
retaining screw
Control panel upper
hinge
Control panel lower
hinge
