Pentair AUTOTROL 762 Series User Manual

Item No. QTY Part No. Description
1 ..............1 ...... 1244650 ..........255 Valve Assembly, w/o
Flow Controls
2 ..............1 ...... 1033784 ..........255 Tank Adapter New Style
3 ..............1 ...... 1010154 ..........O-Ring EPDM
4 ..............1 ...... 1232370 ..........O-Ring EP
5 ..............1 ...... 1235340 ..........Top Plate, 255 Valve, Logix
Series Controller
6 ..............1 ...... 1235341 ..........Spring, One Piece, 255 Valve
7 ..............1 ...... 1236246 ..........Cover, Valve, 255/Performa,
700/860 Series Controller
8 ..............1 ...... 1001404 ..........O-ring Kit: Tank Adapter
9 ..............1 ...... 1040459 ..........O-ring Kit: Piping Boss
10 ............1 ...... 1001986 ..........13/16 inch Rubber Insert
(Optional)
* ..............1 ...... 1000250 ..........Valve Disk Kit - Standard
* ..............1 ...... 1239760 ..........Blending Valve Kit 900/700
Series
11 ............1 ...............................Locking Bar
....... 1031402 ..........English Language Locking
Bar
....... 1031403 ..........French Language Locking
Bar
....... 1031404 ..........German Language Locking
Bar
....... 1031405 ..........Italian Language Locking/
Bar
....... 1031406 ..........Japanese Language Locking
Bar
....... 1031407 ..........Spanish Language Locking
Bar
....... 1006093 ..........Locking Bar Screw - No.
8-9/16 inch
12 ............1 ...............................Camshaft Options:
....... 1235353 ..........Cam 255/700-860 Series
Valve, STD, Black
....... 1236251 ..........Cam 255/700-860 Series
Valve, TWIN, Tan (insert)
13 ............1 ...... 1235361 ..........Motor/Optical Cable
Assembly
14 ............1 ...... 1000226 ..........Screen/Cap Assembly w/
O-ring
15 ............1 ...............................Injector (High Efficiency)
Options:
....... 1035730 ..........“E” Injector (HIgh Efficiency)
- Yellow (6-inch tank)
....... 1035731 ..........“F” Injector (High Efficiency)
- Peach (7-inch tank)
....... 1035732 ..........“G” Injector (High Efficiency)
- Tan (8-inch tank)
....... 1035733 ..........“H” Injector (High Efficiency)
- Lt Purple (9-inch tank)
....... 1035734 ..........“J” Injector (High Efficiency)
- Lt Blue (10-inch tank)
....... 1035735 ..........“K” Injector (High Efficiency)
- Pink (12-inch tank)
....... 1035736 ..........“L” Injector (High Efficiency)
- Orange (13 - 14-inch tank)
16 ............1 ...... 1000269 ..........Injector Cap with O-ring
17 ............1 ...............................Drain Control Assembly with
O-ring:
....... 1000209 ..........No. 7 (1.3 gpm; 4.9 Lpm)
....... 1000210 ..........No. 8 (1.7 gpm; 6.4 Lpm)
....... 1000211 ..........No. 9 (2.2 gpm; 8.3 Lpm)
....... 1000212 ..........No. 10 (2.7 gpm; 10.2 Lpm)
....... 1002130 ..........No. 12 (3.9 gpm; 14.76 Lpm)
....... 1000214 ..........No. 13 (4.5 gpm; 17 Lpm)
....... 1000215 ..........No. 14 (5.3 gpm; 20 Lpm)
18A .......... 1 ...... 1000222 ..........Regenerant Refill Controller,
No Ball, 0.33 gal
18B ................... 1243510 ..........Regenerant Refill Controller
19 ............1 ...............................Air Check Kit
....... 1032416 ..........Air Check Kit 3/8-inch male
....... 1032417 ..........Air Check Kit 1/4-inch male
20 ............1 ...... 1235373 ..........Module, Sensor, Photo
Interrupter
21 ............1 ...... 1030502 ..........Ball, Flow Control
* ..............1 ...... 1033066 ..........New to Old Style Aircheck
Adapter
22 ............1 ...... 1235446 ..........Turbine Cable
* ....................... 1233187 ..........Motor Locking Pin
* ....................... 1244336 ..........Chlorine Generator Kit, 0.33
gpm
* ....................... 1242411 ..........Extension Cord for Cabinet
* ....................... 1239711 ..........Service Kit, Front Mount, 0.1
amp
* ....................... 1239752 ..........Service Kit, Front Mount, 5
amp
* ....................... 1239753 ..........Service Kit, Top Plate Mount,
0.1 amp
* ....................... 1239754 ..........Service Kit, Top Plate Mount,
5 amp
* ....................... 1239979 ..........Cable Harness, Remote
Regen 742
Item No. QTY Part No. Description
255 VALVE EXPLODED VIEW CONTINUED
*Not Shown
AUTOTROL 742/762 Control 255 & Performa Series Valves (263, 268, 268FA) Service Manual • 31

Pentair AUTOTROL 762 Series Specifications

General

Brand	Pentair
Model	AUTOTROL 762 Series
Category	Control Unit
Language	English
