PERFORMA EXPLODED VIEW CONTINUED
Item No. QTY Part No. Description
....... 1001670 ..........1-inch Copper Tube Adapter
Kit
....... 1001608 ..........22-mm Copper Tube Adapter
Kit
....... 1001613 ..........3/4-inch CPVC Tube Adapter
Kit
....... 1001614 ..........1-inch CPVC Tube Adapter
Kit
....... 1001615 ..........25-mm CPVC Tube Adapter
Kit
....... 1001769 ..........3/4-inch NPT Plastic Pipe
Adapter Kit
....... 1001603 ..........1-inch NPT Plastic Pipe
Adapter Kit
....... 1001604 ..........3/4-inch BSPT Plastic Pipe
Adapter Kit
....... 1001605 ..........1-inch BSPT Plastic Pipe
Adapter Kit
....... 1001611 ..........3/4-inch BSPT Brass Pipe
Adapter Kit
....... 1001610 ..........1-inch NPT Brass Pipe
Adapter Kit
....... 1001612 ..........1-inch BSPT Brass Pipe
Adapter Kit
17 ............1 ...... 1235373 ..........Module, Sensor, Photo
Interrupter
18 ............1 ...... 1001986 ..........13/16-inch Rubber Insert
(Optional)
19 ............1 ...... 1235446 ..........Turbine Cable
20 ............1 ...... 1010154 ..........Tank O-ring
* ....................... 1033444 ..........Internal Turbine Meter
* ....................... 1233187 ..........Motor Locking Pin
* ....................... 1299336 ..........Chlorine Generator Kit
* ....................... 1033444 ..........Turbine Assembly
* ....................... 1041174 ..........Valve Disc Kit, Standard
* ....................... 1239979 ..........Cable Harness, Remote
Regen 740F
* ....................... 1239711 ..........Switch Kit, Front Mount, 0.1
amp
* ....................... 1239752 ..........Switch Kit, Front Mount 5
amp
* ....................... 1239753 ..........Switch Kit, Top Plate Mount,
0.1 amp
* ....................... 1239754 ..........Switch Kit, Top Plate Mount,
5 amp
*Not Shown
AUTOTROL 742/762 Control 255 & Performa Series Valves (263, 268, 268FA) Service Manual • 35
