WATER SOFTENER PERFORMANCE DATA SHEET
Model 255-742-075-844 255-742-100-948
255-742-100-1040 255-742-150-1054
Rated Service Flow (gpm) 6.0 10.0 11.0 10.4 Pressure Drop at Rated Service Flow Rate (psi)
8.0 15.0 14.0 15.0
Rated Capacity (grains @ lbs. of salt)
10, 719 @ 2.65
22,110 @ 6.75
25,503 @ 11.25
14,293 @ 3.5 29,480 @ 9.0
34,004 @ 15.0
12,163 @ 3.5 25,087 @ 9.0
28,937 @ 15.0
21,439 @ 5.25 44,220 @ 13.5 51,006 @ 22.5
Rated Efficiency (grains/lb Salt @ lb. of salt)
Not Applicable Not Applicable Not Applicable Not Applicable
Maximum Flow Rate During Regeneration (gpm)
1.7 2.1 2.7 2.7
Sybron C-249NS Ion Exchange Resin (cu ft)
0.75 1.0 1.0 1.5
Backwash - GPM 1.7 2.1
2.7 2.7
Rapid Rinse/purge - GPM
1.7 2.1 2.7 2.7
Operating Pressure: 20 -125 ps
i or 1.4 – 8.8 kg/Centimeter
2
, Operating Temperature: 34 - 100° F or 1.1 – 38° C
Acceptable Salt Type: Sodium Chloride – Pellet or solar salt for water softeners All Systems above tested at 35psi +/- 5 psi,
pH of 7.5 +/- 0.5, Capacity Testing Flow Rate = 50% of the rated service flow rate for the various size systems.
These water softener systems have been tested by WQA and conform to
NSF/ANSI 44 for specific performance claims as verified and substantiated by test data These
systems are not intended to be used for treating water that is
microbiologically unsafe or of unknown quality without adequate disinfection before or after the system. Refer to
the system Installation and Service Manuals for set-up and programming instructions. Contact your local Autotrol dealer for parts and servic
e. See your owner’s manual for warranty information.
Important Notice: For conditions of use, heal
th claims certified by the California Department of Public Health and replacement parts, see product data sheet
Iowa Requirement:
Seller: ______________________________________________________________ Date: _________________________
Buyer: ______________________________________________________________ Date: _________________________
Tested and Certified by WQA against NSF/ANSI Standar
d 44 & NSF/ANSI 372 for “lead free” compliance.
The valve used on this unit is Tested and Certified by WQA to
NSF/ANSI Std. 61 Section 8 for Material Safety Only
PENTAIR Residential Filtration, LLC 5730 North Glen Park Road Milwaukee, Wisconsin 53209 PHONE: (262)-238-4400
SYSTEM SPECIFICATIONS CONTINUED
AUTOTROL 742/762 Control 255 & Performa Series Valves (263, 268, 268FA) Service Manual • 7

Pentair AUTOTROL 762 Series Specifications

General

Brand	Pentair
Model	AUTOTROL 762 Series
Category	Control Unit
Language	English
