Pentair BERKELEY LTH Series User Manual

7
BE30 (11-21-19)
Distance in Feet (Meters) From Motor to Supply
Pump
Model
Catalog # HP
Max. Load
Amps
Phase, Volts Hz
Branch Fuse*
Rating* Amps
0' - 50' 51' - 100' 101' - 200' 201' - 300'
WIRE SIZE (AWG)
LTH-1
S40058 1 14.8/7.4 1 Phase, 115/230v 60 20/15 12/14 12/14 8/14 6/14
S40061 1 ** 3 Phase, 230/460v 60 20/15
S40061- 575T 1 ** 3 Phase, 575v 60 20/15
LTH-1 1⁄ 2
S40063 1-1/2 19.2/9.6 1 Phase, 115/230v 60 25/15 10/14 10/14 8/14 6/12
S40065 1-1/2 ** 3 Phase, 230/460v 60 25/15
S40063-575T 1-1/2 ** 3 Phase, 575v 60 25/15
LTH-2
S40067 2 24.0/12 1 Phase, 230v 60 30/15 12/14 10/14 6/14 6/12
S40069 2 ** 3 Phase, 230/460v 60 30/15
S40069-575T 2 ** 3 Phase, 575v 60 30/15
LTH-2 1⁄2
S40071 2-1/2 26.0/12 1 Phase, 230v 60 30/15 12/14 10/14 6/14 4/12
S40073 2-1/2 ** 3 Phase, 230/460v 60 30/15
S40073-575T 2-1/2 ** 3 Phase, 575v 60 30/15
ELECTRICAL INSTALLATION
WIRING CHART RECOMMENDED WIRE AND FUSE SIZES
HIGH HEAD
(*) Dual element or Fusetron time delay fuses recommended for all motor circuits.
** Consult Customer Service
WIRING CHART RECOMMENDED WIRE AND FUSE SIZES
MEDIUM HEAD
Max. Load Amps
Distance in Feet (Meters) From Motor to Supply
Pump
Model
Catalog # HP
Max. Load
Amps
Phase, Volts Hz
Branch Fuse*
Rating* Amps
0' - 50' 51' - 100' 101' - 200' 201' - 300'
WIRE SIZE (AWG)
LTH-1
S40075 1 14.8/7.4 1 Phase, 115/230v 60 20/15 12/14 12/14 8/14 6/14
S40078 1 ** 3 Phase, 230/460v 60 20/15
S40078- 575T 1 ** 3 Phase, 575v 60 20/15
LTH-1 1⁄ 2
S40080 1-1/2 19.2/9.6 1 Phase, 115/230v 60 25/15 10/14 10/14 8/14 6/12
S40082 1-1/2 ** 3 Phase, 230/460v 60 25/15
S40082-575T 1-1/2 ** 3 Phase, 575v 60 25/15
LTH-2
S40084 2 24.0/12 1 Phase, 230v 60 30/15 12/14 10/14 6/14 6/12
S40086 2 ** 3 Phase, 230/460v 60 30/15
S40086-575T 2 ** 3 Phase, 575v 60 30/15
LTH-2 1⁄2
S40088 2-1/2 26.0/12 1 Phase, 230v 60 30/15 12/14 10/14 6/14 4/12
S40090 2-1/2 ** 3 Phase, 230/460v 60 30/15
S40090-575T 2-1/2 ** 3 Phase, 575v 60 30/15
(*) Dual element or Fusetron time delay fuses recommended for all motor circuits.
** Consult Customer Service
