Pentair BERKELEY S39523 User Manual

17
P15008 (04-15-2023)
KEY
NO.
PART
DESCRIPTION
QTY.
USED
JHC-61HL
JBHC-61S
JHC3-61H
JBHC3-61S
JHD-62HL
JBHD-62S
JHD3-62H
JBHD3-62S
JHE-63HL
JBHE-63S
JHE3-63H
JBHE3-63S
JHF-51HL
JBHF-51S
JHF3-51H
JBHF3-51S
JHG-52HL
JBHG-52S
JHG3-52H
JBHG3-52S
JHHG-53HL
JBHHG-53S
JHHG3-53H
JBHHG3-53S
1/2 HP 3/4 HP 1 HP 1-1/2 HP 2 HP 2-1/2 HP
1
Motor - 115/230v, 1ph,
ODP
1 J218-1651 J218-1652 J218-1653 J218-1655 J218-1656 J218-1657
1
Motor - 230/460v, 3ph
ODP
1 AP100CL AP100DL AP100EL AP100FL AP100GL AP100G5L
2 Water Slinger 1 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009 17351-0009
3 Seal Plate 1 C3-178 C3-178 C3-178 C3-178 C3-181 C3-181
4 Seal Plate Gasket 1 C20-121N C20-121N C20-121N C20-121N C20-122N C20-122N
5 Shaft Seal 1 U109-6B U109-6B U109-6B U109-6B U109-6B U109-6B
6 Impeller - Noryl, 1ph 1 C105-92PNX C105-92PMX C105-92PLX C105-92PBX C105-214PCA C105-214PA
Impeller - Bronze, 1ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6 Impeller - Noryl, 3ph 1 C105-92PNXA C105-92PMXA C105-92PLXA C105-92PBXA C105-214PCA C105-214PA
Impeller - Bronze, 3ph 1 C5-256BA C5-256BAA C5-254BA C5-254BC C5-297BB C5-297B
6A Impeller Screw 1 C30-14SS** C30-14SS** C30-14SS** C30-14SS** C30-14SS C30-14SS
7
Volute Assembly with
Wear Ring
1 C101-284A C101-284A C101-284A C101-284A C101-264 C101-264B
7A Wear Ring 1 C23-27 C23-27 C23-27 C23-27 C23-19 C23-19
8
Pipe Plug, 1/4” NPT
Sq. Hd.
1 - - - - - -
9
Pipe Plug, 1/4” NPT
Hex Hd.
( ) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3) U78-941ZPV (3)
10 Base 1 J104-9F J104-9F J104-9F J104-9F J104-9F J104-9F
10A Motor Pad 1 C35-5S C35-5S C35-5S C35-5S C35-5S C35-5S
11 Stud, 3/8 - 16 x 1-13/16” 4 - - - - - -
12 Hex Nut, 3/8 - 16 4 - - - - - -
12*
Hex Capscrew, 3/8" -
16 x 1-1/2" Lg. (Bottom)
( ) - - - - - -
12*
Hex Capscrew, 3/8" -
16 x 1-1/4" Lg. (Top)
( ) U30-75ZP (4) U30-75ZP (4) U30-75ZP (4) U30-75ZP (4) U30-75ZP (2) U30-75ZP (2)
12*
Hex Capscrew, 3/8" -
16 x 1" Lg. (Bottom)
( ) - - - - U30-74ZP (2) U30-74ZP (2)
Seal Kit
PP1700 PP1700 PP1700 PP1700 PP1700 PP1700
Includes 2, 4, 5
* Not Pictured
**3ph Only
REPAIR PARTS
STA-RITE MODELS (ODP MOTORS)
