Pentair MAX Series User Manual

8
GB
• MAXIMUM TEMPERATURE OF THE
PUMPED FLUID: 50 °C
• MAXIMUM/MINIMUM AMBIENT
TEMPERATURE: 40 °C / 5 °C*
• MAXIMUM NUMBER OF STARTS PER
HOUR: 40 uniformly distributed
• MAXIMUM SUCTION HEIGHT
(recommended): 9 m - Jet, Newjet,
Jetinox, Autojet
• MAXIMUM SUCTION HEIGHT
(recommended): 7 m - Max,
Multinox-A, Automax
• MAXIMUM ADMITTED WORKING
PRESSURE: 6 bar - Jet, Newjet,
Jetinox, Autojet
• MAXIMUM ADMITTED WORKING
PRESSURE: 7 bar - Max
• MAXIMUM ADMITTED WORKING
PRESSURE: 9 bar - Multinox-A
The pump cannot be used for sea water and inflammable, corrosive, explosive or dangerous liquids.
Verify that the electropump never runs without liquids.
WARNING
WARNING
LIMITATIONS
CHAPTER 2
JET, NEWJET, JETINOX, AUTOJET, MAX, MULTINOX-A, AUTOMAX pumps are suitable to pump clean water from wells, tanks, etc.; to
irrigate meadows and flowerbeds; to fill or drain collection tanks or basins; and to wash terraces or small paths.
The electric pumps in this series are centrifugal and self-priming with a “venturi“ system inserted into the body of the pump.
* Below 5° C, drain the electropump to prevent failures or damages caused by frost
MODEL (LWA)** LPA
MAX 80/48
66 dB 58,1 dB
AUTOMAX 80/48
MAX 80/60 69 dB 61,3 dB
MAX 120/60
73 dB 64,6 dB
AUTOMAX 120/60
MULTINOX A 200/40
79 dB 66,5 dB
MULTINOX A 200/52
MULTINOX A 200/65
MULTINOX A 200/80
MODEL (LWA)** LPA
JET 600
75 dB 68,1 dB
JET 800
JET 1000 86 dB 78,01 dB
NEWJET 40/40
78 dB 69,7 dB
NEWJET 45/43
NEWJET 60/50 85 dB 72,7 dB
JETINOX 45/43 78 dB 69,7 dB
JETINOX 60/50
85 dB 72,7 dB
AUTOJET 60/50
JETINOX 70/50
82 dB 70,1 dB
AUTOJET 70/50
JETINOX 90/43
91 dB 83,2 dB
JETINOX 90/50
** Sound emission values obtained in conformity with the
EN 12639 standard.
** Measurement method according to EN ISO 3744.
