Pentair Myers WG20 User Manual

CENTER LINE OF
RAIL SUPPORT FLANGES
HOLDING CLAMPS AND
SUPPORT BRACKET
FOR SHUT-OFF GUIDE PIPE
YOKE LOCKING
SET SCREWS
USE PAPER TEMPLATE FURNISHED
WITH PARTS TO LOCATE DISCHARGE CASTING
AND FLANGES
36” BASIN
48” BASIN
11-1/4
14-1/2
8-1/2
11-3/4
36” BASIN
48” BASIN
CENTER LINE OF DISCH.
PIPE FLANGES
1-1/4 GALV. PIPE PLUG
USE SOFT RUBBER GASKET,
SUPPLIED, BEHIND FLANGES
17-3/8” FOR 36” BASIN
18-1/4” FOR 48” BASIN
LENGTH OF 1” GALV. PIPE RAILS – 1” LESS THAN LENGTH
FROM C OF SUPPORT FLANGE TO BOTTOM OF BASIN
L
RAIL SUPPORT FLANGE
RAIL SUPPORT
YOKE
GUIDE RAILS
1” GALV. PIPE
(BY OTHERS)
DISCHARGE
FLANGE
RAIL LOCKING SET SCREWS
ELEV.
GROUND SURFACE
2” CONDUIT TO
CONTROL BOX
(BY OTHERS)
ELEV.
ELEV.
10”
2” FLANGE TO CONNECT
WATERPROOF
CONNECTION BOX
(USE ONLY IF
CONTROL BOX IS
MOUNTED REMOTE
FROM SUMP)
36” OR 48” CONCRETE PIPE BASIN OR MANHOLE
VALV E SHUT-OFF STEM
INVERT
36” MINIMUM
RAIL SUPPORT
YOKE
5”
SUPPORT
FLANGE
1-1/2” P.V.C. SCHED.
40 PIPE FOR
SHUT-OFF GUIDE
(BY OTHERS)
DISCHARGE
FLANGE
1-1/4 GALV NIPPLE
THREAD ONE END
X 10” LONG
1-1/4 BRONZE
VALV E
1-1/4 x 6” GALV.
NIPPLE
1-1/4 x 3” GALV.
NIPPLE
GUIDE RAILS
1” GALV. PIPE
(BY OTHERS)
DISCH. PIPE
1-1/4 GALV.
(BY OTHERS)
DISCHARGE
CASTING
LENGTH OF DISCH. PIPE
12-1/4” LESS THAN LENGTH
FROM C OF DISCH. PIPE TO
BOTTOM OF BASIN
L
3/8-16 x 2” LG. MACHINE BOLTS & ARRO 3500 SERIES 1-1/2” LG. EXPANSION SLEEVES (TOTAL REQUIRED 32 EACH, BY OTHERS)
USE RUST PROOF PLATED BOLTS AND SLEEVES (WASHERS ARE FURNISHED)
DEPTH OF BASIN TO SUIT INSTALLATION
C DISCH. TO BOTTOM OF BASIN
L
DISCHARGE
1-1/4 PIPE
(BY OTHERS)
C
L
DEPTH TO SUIT INSTALLATION
BELOW FROST LINE
13800A862 11/06/12
4
MYERS DUPLEX LIFT-OUT RAIL SYSTEM IN 36" OR 48" CONCRETE BASIN
