23. Pump out well (if necessary):
Direct pump’s discharge to appropriate location
not connected to system and press Pump Out.
The pump will run at 45 Hz.
Run the Drive in this mode until the well discharge
runs clear, then press STOP button to stop Drive.
Risk of explosion. In Pump Out
mode, pump runs at a constant speed, which can
cause very high pressure if flow is restricted.
4. Verify installation: Make sure that the system
has properly-sized, pressure-relief valve and
pressure tank.
Make sure pressure tank’s precharge is correct.
(See Table 7).
Make sure pump discharge is connected to
system.
5. System Start:
A. Open valves at the ends of lines so that air
will escape during pressurization.
B. Press Auto Start; close valves at the ends of
lines after all air has escaped.
C. The system goes into Constant Pressure
Operation as soon as the transducer
registers the Dry Run Sensitivity parameter
(default is 68 kPa). If system pressure does
not reach thatkPa value within 3 minutes,
the Drive will stop. Press Auto Start again to
restart line fill. If longer priming or line fill
time is required, adjust Fill Time parameter.
(See Table 9).
Changing a Parameter Value
This procedure works for ANY parameter.
A. Press MAINMENU button.
B. Follow the keypress sequence shown in
Figure12:
A shorthand way to remember this is:
• Press ENTER to change a value
• Press ENTER again to save it
• If new value is not saved, any screen change will
result in the loss of the new value.
Table 9 lists all available commands and
parameters for the PENTEK INTELLIDRIVE.
Initial Startup 11
6567 0512
Use arrows to
find parameter
Use arrows
to change value
Press Enter
to save
Press Enter
Figure 12 - Changing parameter value.
