Backside ofoutdoorunit(seeFig.E /F)
24 Terminalscrew1(indoorunitconnection)
25 Terminalscrew2(indoorunitconnection)
26 Terminalscrew3(indoorunitconnection)
Technicaldata
Safety instructions
Indoorunit
Outdoorunit
Explanation of the symbols and terms used:
Danger!
Caution!
Tip!
Danger!
Operatingvoltage: 230V~0Hz
Currentconsumption: max.6W
Mainsconnection: approx.1,5mmainscablewithmainsplug
Outputvoltage: 12VDC(fordoorrelease)
Operatingcurrent: max.1A*(fordoorrelease)
Tonalsequence: approx.80dB(approx.1mdistance)
Operatingtemperature: +5°Cto+40°C
Dimensions: approx.93x72x230mm(wxhxd)(with
Receiverandmountingplate)
*Thedoorreleasemustmeetthesespecifications.
supplycable Corecrosssectionmax.length
0.5mm² 100m
0.8mm² 150m
1.5mm² 200m
Operatingvoltage: fromindoorunit(7VDC)
Dimensions: panelapprox.116x200x16mm(wxhxd)
flushmountboxapprox.98x164x40mm
(wxhxd)
IPprotectiontype: IP20;foruseindryareaonly
The following instructions are for your own safety and satisfaction when
operating the door intercom. Please note that non-compliance with these
safetyinstructionscanleadtoaseriousriskofaccident.
failure to observe this instruction endangers life and
health.
failure to observe this instruction endangers property.
following this advice will help you to achieve optimal results.
Do not leave small children unsupervised with the packaging
material. There is a risk of fatal accident by suffocation.
Do not leave children unsupervised with the device. There is a risk of
fatal accident and injury.
The door intercom must be isolated from the power supply for
installation and connection. Otherwise there is a risk of fatal accident
by electric shock.
Corecrosssectioninrelationtolengthof
Operatingtemperature: -10°Cto+5°C
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
Do not damage any gas, electricity, water or telecommunication lines
when fitting the device. This poses a risk of fatal accident, injury and
damage.
Never expose the device to fire, heat or to temperatures of over 50° C
for any length of time. There is a danger to life from fire.
Handle the cable with care. Install it so that it cannot get damaged
and does not create a stumbling hazard. This otherwise poses a risk
of fatal accident and injury.
Never connect any external voltage to the terminal screws. Otherwise
there is a risk of fatal accident, injury and fire.
Make sure that the plug of the mains cable is pushed completely into
the mains socket when connecting the device. Never touch it with
damp hands. Otherwise there is a risk of electric shock and fatal
accident.
Use the indoor unit in dry areas only. Never allow it to come into
contact with water. Do not cover the air vents with any objects, e.g.
curtains. Do not operate the indoor unit in cupboards or very small
spaces with insufficient ventilation. There is a risk of electric shock,
fire and fatal accident.
Clean the components with a dry or slightly damp cloth only. Keep the
components and cable dry when cleaning. Otherwise there is a risk of
electricshockandfatalaccident.
Do not open the housing of the indoor unit! The device is under high
voltage!Thereisariskofelectricshockandfatalaccident.
Donotpush anyobjectthroughtheopenings.Youcouldtouchliveparts!
Thisposesariskofelectricshock,fatalaccidentandfire!
In the event of damage, isolatethedeviceimmediatelyfrom the mains
supply! Pullthe plugoutofthe mainssocket.Contactthe serviceoffice.
Any repair work must be carried out immediately by a qualified
electrician.Otherwisethereisariskofelectricshockandfatalaccident!
If any object or liquid gets into the components, disconnect from the
mains supply immediately (pull the plug of the mains cable out of the
mains socket immediately). The components must be checked by a
qualified electrician before the device resumes operation. Otherwise
thereisariskofshortcircuit,electricshockandfatalaccident.
Take care to avoid injury when preparing the recess in the wall for
outsideinstallationoftheoutdoorunit.
Make sure beforeconnectionto themainspower supplythat itis230 V
~50Hzinaccordancewithregulations.
Do not cover the indoor unit or outdoor unit with any object. This could
adverselyaffecttheringtoneandvoicetransmissionfunctions.
Make sure that the indoor unit and the outdoor unit do not come into
contactwithwater.
Protect the indoor unit and the outdoor unit from strong magnetic or
electricfieldsandheavymechanicalloadsorvibrations.
Only use thedevicewith thesuppliedoriginal partsorparts suitablefor
it.
Caution!
Check before initial operation that all components are assembled in
accordancewiththeoperatinginstructions.
GB - 14
