Revision: B 6 D04-IFU-0001400
2-2 Appearance
Figure 1. Rigid Laryngostroboscope
2-3 Specifications
Total Length 252 mm
Working Length 189 mm
Outer Diameter 9.5 mm
Actual Visual Field Angle 35 degree
Angled View 70 degree
Depth of Field 2 mm-40 mm
Integral Light Cable Yes
Light Guide Length 1727 mm
Total Length 226 mm
Working Length 186 mm
Outer Diameter 6 mm
Actual Visual Field Angle 35 degree
Angled View 70 degree
Depth of Field 2 mm-40 mm
Integral Light Cable Yes
Light Guide Length 1750 mm
