Page #9 background imageLoading...
Page #9 background image
0 - 0.2mm
MIRROR-
CHARGE
LEVER
SPROCKET
HOOK
FIGURE 13
FILM-
APERTURE
SIDE
TAKE-UP SPOOL
SIDE
FIGURE 14
REWIND
END OF
CAMERA
PARALLEL TO
ENDS OF
CAMERA
COUNTER
GEAR
FIGURE 15

Other manuals for Pentax P3

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Pentax P3 and is the answer not in the manual?

Pentax P3 Specifications

General IconGeneral
ModelPentax P3
Film Format35mm
Lens MountPentax K mount
MeteringTTL center-weighted
Flash Sync1/100 sec
Camera TypeSLR
Shutter Speed1/1000 sec to 1 sec, Bulb
Exposure ModesManual
ISO Range25-1600
ViewfinderPentaprism
FlashHot shoe
Battery2x LR44/SR44
