Pentax WG-3 - Camera Parts and Display Indicators

10
Flash
Self-timer lamp/
Focus assist light
Front
Back
Tripod socket
Remote control
receiver
Shutter
release button
Power button/Power lamp (green)
Lens
Sub-display
(PENTAX WG-3 GPS
only)
Microphones
Remote control
receiver
LED Macro lights
Strap lug
Release latch
Speakers
Display
Battery cover
lock
Battery cover
USB/AV terminal
HDMI terminal
Battery lock lever
Names of Parts and Display Indicators
In this Quick Guide,
the arrow keys to be
pressed are indicated
as shown on the right.
2
3
5
4
2
3
54
