Client Signal
Strength Threshold
This field determines that maximum signal strength each individual client will
receive. The measurement unit is megawatts.
This field determines the maximum clients that can be connected to APs under
this profile.
This field specifies the VLAN ID to tag to management traffic, such as AP to AP
controller communication traffic. The value is 0 by default, meaning that no
VLAN tagging will be applied.
Note: change this value with caution as alterations may result in loss of
connection to the AP controller.
This option is to turn on and off to scan the nearby the AP.
Note: Feature will be automatically turned on with Auto Channel / Dynamic
Output Power
This drop-down menu provides the option to send beacons in different transmit
bit rates. The bit rates are 1Mbps, 2Mbps, 5.5Mbps, 6Mbps, and 11Mbps.
This drop-down menu provides the option to set the time between each beacon
send. Available options are 100ms, 250ms, and 500ms.
This field provides the option to set the frequency for beacon to include delivery
traffic indication message (DTIM). The interval unit is measured in milliseconds.
This field provides the option to set the minimum packet size for the unit to send
an RTS using the RTS/CTS handshake. Setting 0 disables this feature.
Determines the maximum size (in bytes) that each packet fragment will be
broken down into. Set 0 to disable fragmentation.
Select the distance you want your Wi-Fi to cover in order to adjust the below
parameters. Default values are recommended.
This field provides the option to modify the unit wait time before it transmits. The
default value is 9μs.
This field provides the option to set the wait time to receive acknowledgement
packet before doing retransmission. The default value is 48μs.
A
- Advanced feature. Click the button on the top right-hand corner to activate.
Per FCC regulation, the country selection is not available on all models marketed in the US. All US models are
fixed to US channels only.
