BTC22-*
Product Description
2023-11
13
Ambient conditions
Operating temperature Temperature classes:
A: Industrial temperature grade 0°... 55° C (32 ... 131
°F)
Storage temperature -20 ... 60 °C (-4 ... 140 °F)
Relative humidity ≤ 95% at 40°C (non-condensing acc. to EN 60068-2-
78)
Shock resistance 40 g (11 ms) when operating
Vibration resistance 3 g
rms
5 ... 500 Hz
Mechanical specifications
Housing material Aluminum body and sheet metal, painted/powder-
coated
Degree of protection IP40
Mass 1.32 kg
Dimensions 216 mm x 130 mm x 47 mm
Mounting Desktop or wall mounting, VESA mount (100 x 100 mm
and 75 x 75 mm) and DIN rail mounting via optional
adapter
Note Passive cooling, no moving parts
Power supply not included.
