Pepperl+Fuchs FYQLA1-140R-3 User Manual

13
Door Interrupt System with FYQLA1-140R-3 Logic Amplier
Distance
Offset
Magnet actuator
Hall effect sensor
Sensing distance mm (in)
Oset Max. Actuator
Distance
O Distance
0 (zero) 2.5 (0.1) 10 (0.4)
3.8 (0.15) 1.3 (0.05) 10 (0.4)
7.5 (0.3) 0 (zero) 10 (0.4)
25.4 12.7
2 x ø5
39
25.4
39
Cable Length
50FY41 hall eect sensor
52FY31 magnet actuator
25.4 12.7
2 x ø5
39
25.4
39
Device dimensions
(for reference only—dimensions in mm)
Nominal oset distances

Pepperl+Fuchs FYQLA1-140R-3 Specifications

General

Brand	Pepperl+Fuchs
Model	FYQLA1-140R-3
Category	Amplifier
Language	English
