Door Interrupt System with FYQLA1-140R-3 Logic Amplier

Intended use

The door interrupt system monitors up to six input devices. The external devices

are individually wired to the system and the signals are evaluated to determine if

one of the input devices is in the open state.

The FYQLA1-140R-3 must be used in accordance with its intended

purpose. The system must be installed according to regulations for

safeguarding from hazardous locations or areas being entered, or as

a safety relay for safety components appropriate for the described

conditions. When used dierently, the intended function of the system

is not guaranteed. Appropriate measures should be taken such that

any forseeable misuse is prevented

Safety system test

Only a qualied trained person should perform this test. Any

problems detected as a result of this test must be repaired by

qualied personnel before operating the equipment! DO NOT operate

the equipment if problems are detected or serious injury could result!

The purpose of this test is to verify the function of each switch and

control component in the safety system. The person performing the

test should be familiar with the dierent guards and controls on the

equipment. This test should be performed daily. If the machine is not

in continuous operation, test before each use. See the Daily inspection

ow diagram, pages 8-9.

Regular maintenance testing

It is recommended to test the door interrupt system regularly to verify proper

operation on a daily schedule. These should be performed and documented by

qualied personnel. See test sequence, Daily inspection, pages 8-9.

This safety device and associated equipment should be tested

regularly by qualied personnel familiar with the principles and

procedures in this manual. If the testing indicates a problem with this

device or system, the equipment is not safe to operate. Call qualied

personnel immediately to locate and repair the fault.

This safety device and associated equipment should be tested when

any change or modication is done to the device and/or setup by

qualied personnel familiar with the principles and procedures in

this manual. If the testing indicates a problem with this device or

system, the equipment is not safe to operate. Call qualied personnel

immediately to locate and repair the fault.

Warning

Note

Pepperl+Fuchs FYQLA1-140R-3 User Manual
