Compact Fieldbus Power Hub,Generic Interface
Specification
2014-10
13
Motherboard Types MBHC-FB-8R*
Isolated Power Supply Module Type HCD2-FBPS-1.500
Isolated Power Supply Module Type HCD2-FBPS-1.23.500
Vibration resistance 1 g , 10 ... 150 Hz
Pollution Degree max. 2, according to IEC 60664
Corrosion resistance acc. to ISA-S71.04-1985, severity level G3
Mechanical specifications
Connection type pluggable , screw terminal or spring terminal
Degree of protection IP20
Directive conformity
Electromagnetic compatibility
Directive 2004/108/EC EN 61326-1:2013
Standard conformity
Electromagnetic compatibility NE 21:2011
Degree of protection IEC 60529
Fieldbus standard IEC 61158-2
Shock resistance EN 60068-2-27
Vibration resistance EN 60068-2-6
Supply
Connection redundant
Rated voltage 19.2 ... 35 V SELV/PELV
Rated current 16 A
Power loss typ. 0.4 W per segment
Indicators/operating means
Fault signal VFC alarm 1 A, 50 V DC, normally closed
Supply
Rated voltage 19.2 ... 35 V DC
Power loss typ. 1.6 W
Fieldbus interface
Rated voltage 28 ... 30 V
Rated current 500 ... 10 mA
Short-circuit current 550 mA
Indicators/operating means
LED ERR red flashing: short-circuit or undervoltage at output
LED PWR green if U
out
> 28 V
Data for application in connection with Ex-areas
Outputs
Voltage 30 V
Supply
Rated voltage 19.2 ... 35 V DC
Power loss typ. 1.6 W
