Pepperl+Fuchs HD2 Series User Manual

2014-10
14
Compact Fieldbus Power Hub,Generic Interface
Specification
For information on the technical data of the respective diagnostic modules, refer to the
respective data sheets, manuals or instructions of the diagnostic module used.
Fieldbus interface
Rated voltage 21 ... 23 V
Rated current 500 ... 10 mA
Short-circuit current 550 mA
Indicators/operating means
LED ERR red flashing: short-circuit or undervoltage at output
LED PWR green if U
out
> 21 V
Data for application in connection with Ex-areas
Outputs
Voltage 24 V

Pepperl+Fuchs HD2 Series Specifications

General

Brand	Pepperl+Fuchs
Model	HD2 Series
Category	Power Supply
Language	English
