H-System – Isolated Barriers and Termination Boards
Product Specifications
Connecting the Control Side
The termination board on the control side can be connected via the following connection
options:
Screw terminals
Figure 2.11 Connection example: control-side screw terminals
Spring terminals
Figure 2.12 Connection example: control-side spring terminals
Sub-D plug
Figure 2.13 Connection example: control-side Sub-D plugs
Control-system specific plug
Figure 2.14 Connection example: control-side system plugs
