Establishing the HART Communication
Establish the HART communication via HART plug and HART multiplexer.
HART plug
Figure 2.15 Connection via control-side HART plug
HART multiplexer
Figure 2.16 HART multiplexer connection
PWR
HART TXFAULT
OFFON
HiD
Mux
2700
Hart
Note
See corresponding datasheets for further information.
Note
See corresponding system descriptions of the control system manufacturer
for further information.
