Pepperl+Fuchs IDM-Z1-264-M-2D-J1-BT-N-N0 - Page 27

IDM-Z1-264-M-2D-J1-BT-N-N0, IDM-Z1-164-M-1D-J1-BT-P-N0
Accessories
2022-12
27
Bluetooth® Handheld Reader Accessories for VisuNet HMI Applications
Item Num-
ber
Product Name Description Photo
#70158516 IDM-Z1-x64-B-J1-BT-N0 Bluetooth® reader base station &
charger
Ex-protection: ATEX & IECEx Zone
1/21
Radio Interface: Bluetooth®
Protocol: USB/Serial (depends on
connection cable)
Compatible with IDM-Z1-x64-M-*
Bluetooth® code readers
NOTE: Connection cable not
included. Please order separately!
#70158517 IDM-Z1-x64-B-N0-BT-N0 Bluetooth® reader base station &
charger
Ex-protection: non-Ex, for use in
non-explosion-hazardous area only!
Radio Interface: Bluetooth®
Protocol: USB/Serial (depends on
connection cable)
Compatible with IDM-Z1-x64-M-*
Bluetooth® code readers
NOTE: Connection cable not
included. Please order separately!
#70115392 IDM-Z1-x61-C-N0-BT-N0 Charger cradle for 1D & 2D Blue-
tooth® reader
Ex-protection: non-Ex, for use in safe
area only!
Compatible with IDM-Z1-x64-M-*
Bluetooth® code readers
NOTE: Please order connection
cable separately!
#548396 HOLDER-BRACKET-
XX00-IDMx61-B-N
Bracket to mount IDM-Z1-x64-B-J1-
BT-N0 Base station to AG-XX00
housing.
- Material: Stainless steel AISI 304
(1.4301)
- Assembly: Right side of AG-XX00
housing
- Includes bracket and installation
materials
- Note: Base station and cables not
included!
#548395 HOLDER-BRACKET-AG1-
IDMx61-B-N0
Bracket to mount IDM-Z1-x64-B-J1-
BT-N0 Base station to AG1 housing
- Material: Stainless steel AISI 304
(1.4301)
- Assembly: Right side of AG1 hous-
ing
- Includes bracket and installation
materials
- Note: Base station and cables not
included!
