Z-System – Zener Barriers
Installation
2016-03
21
Figure 3.7 Insulated mounting (individual grounding)
1 Single socket ZH-Z.ES
2 Zener barrier
3 35 mm DIN mounting rail according to EN 60715
4 Adapter ZH-Z.AB/SS
5 Grounding bar ZH-Z.NLS-Cu3/10
6 Grounding bar feed ZH-Z.LL
7 Spacer ZH-Z.AR.125
8 Terminal ZH-Z.AK16
1
2
3
4
5
6
7
8
