Z-System – Zener Barriers
Installation
Figure 3.5 Equipotential bonding via the DIN mounting rail
Figure 3.6 Insulated mounting (group grounding)
1 Terminal block USLKG5
2 Zener barrier
3 35 mm DIN mounting rail according to EN 60715
1 Terminal block USLKG5
2 Zener barrier
3 35 mm DIN mounting rail according to EN 60715
4 Adapter ZH-Z.AB/NS
1
2
3
1
2
3
4
