3. Installation of the Perfect Draft BBQ Blower with Safely Hook and
Heat Shield
The face of the Blower has a slotted attachment on the front. This attachment
is used to slide over the included safety hook to prevent the blower from falling in
the event of an unforeseen incident, causing the blower to be damaged and
voiding the warranty. There are 2 ways to connect The Heat Shield. 1. You can
slide it behind the slotted attachment on the front of the Blower. 2. You can place
the Heat Shield on the firebox then attach the BBQ Blower on the hook. Move
the heat shield in place until the entire front plate is covered and slide it on the
safety hook on your firebox. The BBQ Blower is ready to use.
The Heat Shield is attached to
the front of the Blower, and the
Blower is connected on the
Safety Hook. Notice there is no
gaps between the Heat Shield
and the face of the Blower.
Every firebox is designed
different so you need to locate
the best place to attach the
safety hook. Once you have
located the proper location for
the safety hook. Drill a 3/8” hole
and secure the hook using the
bolt and wing nut. Now you can
attach the BBQ Blower on the
hook.
You can place the Heat Shield
behind the slotted metal face plate.
You can place the Heat Shield on
the firebox then attach the BBQ
Blower on the hook. The force of
the magnets will try to reposition the
shield, adjust it once have attached
it to the firebox .you slide the hook
through the metal plate opening
