Perfect Draft BBQ BLOWER - Controlling the BBQ Blower in Manual mode; Manual Mode Control Panel Features

6
1. Turn the power button on.
2. Turn the Auto Control switch on
3. Connect the 3.5mm temperature plug into the control panel
4. Set the desired temperature using the temperature knob
5. Throttle the stack damper cover 75% - 85% closed
6. Let the Perfect Draft BBQ Blower do its job
CAUTION:
Always connect the Heat Shield to the BBQ Blower while it’s connected to the fire
box failure to do so can result in damage to the outer shell of the Blower. If the BBQ
Pit temperature exceeds 400 degrees disconnect the BBQ Blower until the
temperature drops below 400 degrees.
6. Controlling the BBQ Blower in Manual mode
2. Automatic Switch is ON
In the Down Position
1. Power Switch is ON in the
down position
3.
Plug the charger in here to recharge the
battery. The indicator light on the head
of the charger will show green when fully
charged.
4.
Connect Temperature Probe Here
