Air pressure (P.S.I.) ............................................................................... 90
Average air consumption (C.F.M.) ........................................................... 4
Free speed (R.P.M.) ......................................................................... 3,500
Air inlet (N.P.T.) ..................................................................................... 1/4
Hose size (I.D.) ................................................................................ 3/8 in.
Length (IN.)........................................................................................... 7.6
Weight (LBS.) .......................................................................................2.0
IMPORTANT SAFETY INFORMATION
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines or power tools in damp or wet
locations. Don’t expose to rain. Keep work area well lighted. Do not use electrically
powered tools in the presence of flammable gases or liquids. Do not bring combustible
materials near the tools.
3. As with any tool, use common sense when operating. Do not wear loose clothing or
jewelry that could become caught by moving parts, causing injury. Operate tool a safe
distance from yourself and others in the work area.
4. Keep children away. Children must never be allowed in the work area. Do not let them
handle machines, tools, hoses or extension cords.
5. Store idle equipment. When not in use, tools must be stored in a dry location to inhibit
rust. Always lock up tools and keep out of reach of children and other untrained
persons. Switch off all unused electrical tools when stored. Tools are dangerous in the
hands of untrained users.
6.
Always wear approved eye protection when using tools. If raising dust, wear a suitable mask.
Specifications are subject to change without notice.
WARNING. READ, UNDERSTAND AND FOLLOW ALL INSTRUCTIONS AND WARNINGS
BEFORE OPERATING THIS PRODUCT. FAILURE TO DO SO MAY
RESULT IN FIRE, ELECTRICAL
SHOCK, PERSONAL INJURY AND/OR PROPERTY DAMAGE AND WILL VOID WARRANTY.
This instruction manual is intended for your benefit. Please read and follow the safety, installation, maintenance and troubleshooting
steps described within to ensure your safety and satisfaction. The contents of this instruction manual are based upon the latest
product information available at the time of publication. The manufacturer reserves the right to make product changes at any time
without notice.
SAFETY GUIDELINES / DEFINITIONS
WARNING: Read and understand this entire instruction manual before attempting to assemble, install, operate or maintain
this product. Failure to comply with the instructions may result in serious personal injury and/or property damage!
The following signal words are used to emphasize safety warnings that must be followed when using this product:
DANGER:
Indicates an imminently hazardous situation
that, if not avoided, WILL result in death or serious injury.
WARNING:
Indicates a potentially hazardous situation that,
if not avoided, COULD result in death or serious injury.
CAUTION:
Indicates a potentially hazardous situation that,
if not avoided, MAY result in minor or moderate injury.
NOTE: Indicates important information, which if not
followed, MAY cause damage to equipment.
SPECIFICATIONS:
7. Work Safe. When wearing gloves to operate the tool, make sure that the gloves do not
interfere with operating the Trigger. Test your gloves with the Trigger before attaching
the unit to an air source. Keep your finger away from the Trigger until you are ready to
work. Never start the tool unless you have a firm grip with both hands and you are
positioned at your work piece or area. Before using the tool, know what is directly
underneath the work area or work piece. The tool can quickly penetrate material. If
working directly on the ground, make sure you are not directly above shallow cables,
lines, or pipes. Keep your limbs and body clear of the tool. If an accessory or
attachment breaks off, the tool tends to surge forward suddenly. Operate tool a safe
distance from yourself and others in the work area. Make sure the immediate area is
clear of other people or animals. Spectators must stay at a safe distance. Never point
the tool or the air hose (not included) at anyone. Keep proper footing and balance at
all times. Do not reach over or across running machines, hoses, etc.
8. Do not operate any tool if under the influence of alcohol or drugs. Read warning labels
on prescriptions to determine if your judgment or reflexes are impaired while taking
drugs. If there is any doubt, do not operate any tool.
9. Be sure air is in OFF position when connecting tool to air supply.
10. Use only those accessories that are designed for use with tools. For example, with
impact wrenches do not use ordinary sockets. Use impact sockets for all air tools.
11. Be sure to disconnect tool from air supply before changing accessories, performing
service on tool and when not in use.
12. Follow air source manufacturers' directions for connection of regulators, filters, and
other accessories to air source. Do not install quick couplers directly on tool as they
put unnecessary strain on the air inlet threads possibly causing them to wear out
prematurely. Instead, install them on a short length of air hose attached to the tool.
13. Check for damaged parts. Before using any tool, any part that appears damaged
should be carefully checked to determine that it will operate properly and perform its
intended function. Check for alignment and binding of moving parts; any broken parts
or mounting fixtures; and any other condition that may affect proper operation. Any
part that is damaged should be properly repaired or replaced by a qualified technician.
14. Maintenance. For your safety, maintenance should be performed regularly by a
qualified technician using original PERFORMANCE TOOLS® replacement parts.
Failure to do so can lead to accidents for the operator. Use of any other parts will void
the warranty. Only use accessories intended for use with this tool. Approved
accessories are available from Performance Tool®. Use only accessories that are
recommended by the manufacturer for your model. Accessories that may be suitable
for one tool may become hazardous when used on another tool.
WARNING:
Repetitive motions or exposure to vibration may be harmful to your hands and arms.
WARNING: Some dust created by power sanding contains chemicals known to the State
of California to cause cancer, birth defects or other reproductive harm. Example of this type
of chemical are:
-lead from lead based paints,
-Crystalline Silica from bricks and cement or other masonry,
-Arsenic and Chromium from chemically treated lumber.
Your risk from these exposures varies, depending on how often you do this type of work. To
reduce your exposure: work in a well ventilated area and work with approved safety
equipment, such as dusk masks that are specially designed to filter out microscopic particles.
WARNING:
The warnings, cautions, and instructions discussed in this instruction manual
cannot cover all possible conditions and situations that may occur. It must be understood by the
operator that common sense and caution are factors which cannot be built into this product, but
must be supplied by the operator. Read and understand all of the instructions provided in the
instruction manual of this product, as well as, any other tool (s) used with this product.
IMPORTANT SAFETY INFORMATION
Punches (2 PC) ............................................................................. M553C
Air Nibbler Replacement Die ......................................................... M554C
REPLACEMENT PARTS AVAILABLE:
