Page #7 background imageLoading...
Page #7 background image
7
1 Housing 1
2 O-ring 1
3 Washer 1
4 Spring 1
5 Washer 1
6 Valve Stem 1
7 Spring 1
8 O-Ring 1
9 Screw 1
10 Washer 1
11 Orifice 2
12 O-Ring 1
13 Tre-in 1
14 Screw 2
15 M570ST* Steel Nozzle 4
16 Trigger 1
17 Trigger Pin 1
18 Spanner 1
19 Black Rubber Tube 1
20 Steel Pipe 1
# Part Number Description Quantity
PARTS LIST
*Call Customer service for replacement parts: 1-800-497-0552
TROUBLESHOOTING
INSUFFICIENT POWER:
Probable Cause Solution
Dirty or clogged air passages Flush and lubricate tool, drain air tank
and supply line
Insufficient air supply Increase line pressure, make sure
compressor matches tool's air pressure
and consumption needs
Air leakage Use PTFE tape at all fittings and joints.
Check tool for worn or damaged
O-rings & seals.
Worn/damaged wear &
tear parts Replace as necessary.
Tool matching Be sure you are using a tool suited for
the sanding requirements of the
job at hand.
