1 Hammer Case 1
2 Grease Fitting 1
3 Hammer Case Bushing 1
4 Socket Retainer 1
5 O-Ring 8X1.8 1
6 Standard Anvil 1
7 Hammer Pin 2
8 Hammer 2
9 Hammer Frame 1
10 End Plate Gasket 1
11 Housing 1
12 Rear Rotor Bearing 1
13 Front End Plate 1
14 Cylinder 1
15 Throttle lever Pin 4X12 3
16 Rotor Blade 6
17 Rotor 1
18 Rear End Plate 1
19 Rear Rotor Bearing 1
20 Trigger 1
21 O-Ring 3X1.15 1
22 Spring 1
23 Throttle lever Pin 3X18 1
24
Rear Rotor Bearing Retainer
1
25 Reverse Valve Bushing 1
26 Valve Seat 1
27 Throttle Valve 1
28 Spring 1
29 O-Ring 14X3 1
30 O-Ring 1
31 Air Inlet 1
32 Bust Screw 1
33 Band 1
34 Screen 1
35 Cover 1
36 End Plate Gasket 1
37 O-Ring 45X2 2
38 Reverse Valve 1
39 O-Ring 8X1.8 1
40 Back Cover 1
41 Even washer 4
42 Hammer Case Bushing 4
43 Spring 1
44 Steel Ball 1
45 Regulator Knob 1
46 Screw 1
# Description Quantity # Description Quantity
REPLACEMENT PARTS LIST
INSUFFICIENT POWER:
Probable Cause Solution
Dirty or clogged air passages Flush and lubricate tool, drain air tank
and supply line
Insufficient air supply Increase line pressure, make sure
compressor matches tool's air pressure
and consumption needs
Air leakage Use PTFE tape at all fittings and joints.
Check tool for worn or damaged O-rings
& seals.
Worn/damaged wear &
tear parts Replace as necessary.
Tool matching Be sure you are using a tool suited for
the requirements of the job at hand.
TROUBLESHOOTING
