PerformancePro ARTESIAN 2 - Parts

Clamp Ring
Lid
Basket
Lid o-ring
Nut
Tailpiece
Tailpiece
o-ring
Drain plug
& o-ring
Volute
Union
Assembly
o-ring
Impeller
Bracket
Motor Base
Motor
1 1/8” Hex Bolts (6)
7/8” Hex Bolts (4)
Bracket o-ring
Mechanical
Seal
Union
Assembly
Bracket Bore
o-ring
Parts
ITEM DESCRIPTION PART NUMBER
Bracket
Bracket
APS-3-30
Bracket Bore O-Ring
Bracket Bore O-Ring
PBO-10
Bracket O-Ring Bracket O-Ring
APO-3-20
Diffuser O-Ring O-Ring for Diffuser Nose
APD-06.6
Diffuser
Diffuser Large Vane (for #4 - 7 Impellers)
APD-2-08
Diffuser XL Vane (for #8 - 9 Impellers)
APD-09
Impeller
Impeller for A2-1/8-39 (#4) T: 4.35
A1H
Impeller for A2-1/4-58 (#6) T: 4.92
A2H
Impeller for A2-1/4-47 (#4) T: 4.92
A1H
Drain Plug
Polypropylene Drain Plug with Buna O-Ring (1)
PPD-10
Hardware
Stainless Steel Hardware Set (All except 1.5 - 3 HF)
MPH-30
Diffuser Set Screw
Set Screw for Diffuser (All except 1.5 - 3hp HF)
DSS-1
Bearings
Motor Bearings - 03
BEARING-03
Set Screw for Diffuser (1.5 - 3 hp HF)
DSS-2
Stainless Steel Hardware Set (1.5 - 3 HF only)
MPH-30.5
Impeller for A2-1/2-76 (#8)
T: 5.12
A1/2L
Impeller for A2-1/3-63 (#7)
T: 5.12
A3H
PARTS
