TABLE OF CONTENTS
Rules for Safe Operation…………..……………………………….........Page 3
Description…………..…………………………………………............Page 10
Assembly…………..…………………………………………........... . . . Page11
Adjustments…………..…………………………………………........ .Page 13
Operation…………..…………………………………………..............Page 14
Maintenance…………..……………………………………….............Page 23
Troubleshooting…………..…………………………………….............Page 23
Accessories…………..…………………………………….................. Page 24
Warranty…………..……………………………………………...........Page 25
SPECIFICATIONS
Miter Saw Specifications:
Model: 240-3687
Motor: 120V~60Hz, 15A
Speed: 5500 RPM, no load
Blade: 10˝ (25.4 cm) (40-tooth) carbide-tipped
Laser: CLASS llla
Laser wavelength: 650 nm
Laser max outpower: ≤ 2.5 mW
sliding length: 8 1/4”
Weight: 38 lb 9 oz (17.5 kg)
Cutting capacity: 3-1/8 x 11-5/8" crosscut at 0° miter, 0° bevel
3-1/8 x 8" miter at 45° miter, 0° bevel
1-1/2 x 11-5/8" bevel at 0° miter, 45° bevel
1-1/2 x 8" compound at 45° miter, 45° bevel
