CHANGING THE COLLET
Some accessories require the use of
different sized collets. Collet sizes can be
1/16” (1.6 mm), 3/32” (2.4 mm) and
1/8” (3.2 mm). It is important to ensure that
the collet size matches the accessory.
NOTE: This tool includes two of the most
commonly used collets: 3/32” (2.4 mm)
and 1/8” (3.2 mm).
WARNING: Using a collet that is
too large for the accessory will result in
the accessory possibly being thrown
from the tool causing serious injury.
1. Turn the tool switch OFF.
2. Depress the spindle lock button (1)
and slowly turn the collet nut (2) until
the spindle lock button locks the
spindle (Fig. 8).
3. While holding the spindle lock button
down, turn the collet nut counter
clockwise until it is removed.
4. Remove the collet (3) by pulling it out
of the spindle (4).
5. Insert the replacement collet into the
spindle and replace the collet nut by
turning it clockwise while holding the
spindle lock button down.
NOTE: Do not tighten the collet nut without
an accessory installed in the collet. You
will damage the collet.
