Key #
Part #
Part Name
Quantity
31
4010010031
Bearing 626-2Z
1
32
2040080056
Big gear
1
33
2030020123
Washer Φ10.5xΦ20x1.5
1
34
2040290104
Drive wheel shaft
1
35
1061040007
Switch
1
36
1250010003
Terminal block
1
37
4030010099
Screw ST3.9x14
12
38
2030050002
Cord clamp
1
39
3140010004
Cord sleeve
1
40
1190290013
UL cord
1
41
1230030025
Brush holder
2
42
4030010020
Screw ST2.9x6
4
43
2050020027
Brush spring
2
44
1230010141
Brush
2
45
1130010266
PCB
1
46
4090040020
Rivet
1
47
2030100083
Driven wheel support
1
48
2030020267
Washer Φ6.2xΦ12x1
1
49
2050060263
Spring
1
50
3120100060
Belt tension release lever
1
51
4010020003
Roller bearing
2
52
2020140016
Base
1
53
2030020368
Washer Φ8.2xΦ11x0.5
1
54
4060010037
Nut M8x25
1
55
3150230010
Drive wheel
1
56
3140080050
Rubber sleeve for drive wheel (55)
1
57
4030010243
Screw ST3.9x10
4
58
3160090118
Drive belt wheel cover
1
59
3150030023
Drive belt
1
60
2020160032
Small belt wheel
1
61
3150160256
Drive belt housing
1
62
13150030022
Large wheel
1
63
3180040127
Dust port
1
64
4010010048
Bearing 608-2RS
11
65
3150240031
608 bearing dust excluding ring
1
66
3150010123
Fan
1
67
3150050100
Air baffle
1
68
1010090003
Rotor
1
69
3150130030
Dust excluding ring
1
70
4010010053
Bearing 607-2RS
1
71
3180020041
Dust box
1
72
2040140063
Bolt
1
73
2020140017
Clamp
1
74
2030160164
Clamp plate
1
75
2040160219
Pin
1
PARTS LIST
