Page #18 background imageLoading...
Page #18 background image
18
WARNING: When servicing, use only original equipment replacement parts. The use of any
other parts may create a safety hazard or cause damage to the belt sander.
Any attempt to repair or replace electrical parts on this belt sander may create a safety hazard unless
repairs are performed by a qualified technician. For more information, call the Toll-free Helpline, at
1-866-349-8665 (Monday through Friday 9am 5pm Eastern Time).
Always order by PART NUMBER, not by key number.
Key #
Part #
Part Name
Quantity
1
2030010067
Base
1
2
4030010125
Screw T3.9x35
3
3
3160040115
Base cover
1
4
4020020009
M4x6 screw
2
5
2030030299
Bumper block
1
6
4610010002
Steel wire
1
7
2040160217
Driven wheel shaft
1
8
2020160033
Driven wheel bushing
1
9
4010020002
Roller bearing
2
10
4030010106
Screw ST3.9x19
6
11
3011320001
Housing
1
12
4100020037
Snap ring 6mm
1
13
2030020369
Washer Φ7.2xΦ10.5x1
1
14
2040160218
Pin Φ5x76
1
15
3160040114
Movable guard
1
16
4020080010
Screw Φ5x12
1
17
4040040001
Spring washer
1
18
2030020367
Washer Φ5xΦ17x2
1
19
3120070059
Front handle
1
20
4030010034
Screw ST2.9x16
9
21
2040290043
Front handle shaft (19)
1
22
2030020200
Washer Φ8.5xΦ16x1
1
23
2040160099
Front handle latch pin
1
24
2020230001
Front handle locking lever
1
25
4030010169
Screw ST4.2x55
2
26
1020090003
Stator
1
27
3120060070
Belt tracking knob
1
28
2050050056
Torsion spring
1
29
4010010106
Bearing 627-2RS
1
30
2040040126
Belt wheel shaft
1
!
PARTS LIST
