INSTALLING CABLE AND CHAIN
Look in the box for:
Trolley Sha/Chain Assembly
Master Link
WARNING
To prevent SERIOUS INJURY:
• DO NOT connect power until instructed.
• Keep hands and fingers clear from sprocket during
operation.
• Wear gloves when installing chain and cable.
• Keep hands and fingers away from joints and
possible sharp edges.
Insert cable through circular hole in trolley. Pull
cable through pulley slot and toward power head.
Chassis
Pull chain with box along the right side of the rail
towards trolley and then remove box.
7"
(17.8 cm)
Loosely attach trolley sha with chain connector. 5 complete turns will be sufficient.
Pull trolley lock lever down to unlock. Insert trolley
sha through the trolley and pull lever back up.
End of
Chain
Trolley in
engaged
position
Align end of chain around sprocket and extend chain
past the le side of the chassis, approximately 7" (17.8
cm). Sprocket teeth must engage the chain.
To Next Page
