Perkin-Elmer Lambda 365 - Configuration of Water Jacketed 8-Position Multi-Cell Holder

09931251D
3
Configuration of Water Jacketed 8-Position Multi-Cell Holder
Figure 2 Water Jacketed 8-Position Multi-Cell Holder Configuration
- Used to fix a cell holder, a base plate or a front plate for Lambda 365.
- Spare screws (2ea) are enveloped with the accessory.
Figure 3 Phillips round headscrew with washer (M4 *12L)
Figure 4. Male connector of quick coupling (2 each)
