Perkin-Elmer Lambda 365 User Manual

09931251D
2
Dimensions and Specifications
Dimensions
Physical Characteristic Specification Comment
Outline
Height (mm) 143
Width (mm) 135
Depth (mm) 354
Inner
Height (mm) 35
Suitable for the Standard
Cell
Width (mm) 14
Depth (mm) 12.6
Weight (kg) 2.3
Specifications
Physical Characteristic Specification Comment
Space between cells (mm) 10.4
Moving distance of one cell (mm) 11.5
Moving distance of eight cells (mm) 80.5
Moving time of one cell (sec) 1.3
Moving time of eight cells (sec) 8.5
Environmental Conditions for Operation
Specification Comment
RT~ 100℃
Controls the temperature using Circulator

Perkin-Elmer Lambda 365 Specifications

General

Wavelength Range	190 - 1100 nm
Power Requirements	100-240 VAC, 50/60 Hz
Photometric Accuracy	±0.002 Abs (at 1 Abs)
Baseline Stability	< 0.0005 Abs/hour
Light Source	Deuterium and Tungsten-Halogen lamps
Display	Touchscreen
Photometric Repeatability	± 0.001 Abs
