09931251D
1. Prepare the Lambda 365 Spectrophotometer to install this accessory.
2. Connect the power cord and the communication cable. DO NOT turn on the power of the
instrument!
3. Remove the two Phillips round head screws with washer (M4*12L) to disassemble the existing cell
holder and base plate
Figure 5. Location of the Phillips round head screws with washer
4. Pull out the cell holder and base plate by hand.
Figure 6. Pulling out the cell holder and base plate
CAUTION
ATTENTION
Make sure the instrument is turned off while installing this accessory.
Assurez-vous que l’instrument est é
teint lors de l’installation de cet
accessoire.
