i06280431
Monitoring System
(Engine Warning Indicators)
Table 3
Table for Warning Indicators
Warning Indicator
Shutdown
Indicator Indicator State
Description of the
Indication
Engine Status Operator Action
ON ON Indicator Check Keyswitch in the ON posi-
tion all Indicators should il-
luminate for 0.5 of a
second.
Power ON, Indicator
check
Engine is not
operating.
If any of the Indicators will
not illuminate during the
Indicator check, the fault
must be investigated
immediately.
If any Indicator stays illu-
minated or flash, the fault
must be investigated
immediately.
OFF OFF No Fault
-
Engine operating
normally.
None
Level 1
ON (Solid) OFF Level 1 An active diagnostic code
is present.
The engine is operat-
ing, but one or more
diagnostic codes are
present.
As soon as possible the
diagnostic code should be
investigated.
Level 2
Flashing OFF Level 2 The ECM has detected an
abnormal condition.
If enabled, the engine
will be derated.
Stop the engine.
Investigate the fault.
Level 3
Flashing ON Level 3 Engine condition is
abnormal.
The engine will auto-
matically shutdown.
If shutdown is not en-
abled, the engine can
operate but may
course damage .
Stop engine immediately.
Investigate the fault.
i06542459
Monitoring System
If the Shutdown mode has been selected and the
warning indicator activates, engine shutdown
may take as little as 20 seconds from the time the
warning indicator is activated. Depending on the
application, special precautions should be taken
to avoid personal injury. The engine can be re-
started following shutdown for emergency ma-
neuvers, if necessary.
NOTICE
The Engine Monitoring System is not a guarantee
against catastrophic failures. Programmed delays
and derate schedules are designed to minimize false
alarms and provide time for the operator to stop the
engine.
The following parameters are monitored:
• Engine speed/timing
• Engine temperature and pressures sensors
• Atmospheric pressure (Barometric pressure)
• Fuel temperature
• Battery voltage
40
SEBU9075-03
Operation Section
Monitoring System
