i02801131
Maintenance Section
Refill Capacities
Refill Capacities
Lubrication System
The refill capacities for the engine crankcase reflect
the approximate capacity of the crankcase or sump
plus standard oil filters. Auxiliary oil filter systems will
require additional oil. Refer to the OEM specifications
for the capacity of the auxiliary oil filter. Refer to the
Operation and Maintenance Manual, “Maintenance
Section” for more information on Lubricant
Specifications.
402C-05 Engine
Table 9
402C-05 Engine
Refill Capacities
Compartment or System
Minimum Maximum
Crankcase Oil Sump
(1)
1.61 L
(1.7 qt)
2.01 L
(2.1 qt)
Total Lubrication System
(2)
(1)
These values are the approximate capacities for the crankcase
oil sump which includes the standard factory installed oil filters.
Engines with auxiliary oil filters will require additional oil. Refer
to the OEM specifications for the capacity of the auxiliary oil
filter.
(2)
The Total Lubrication System includes the capacity for the
Crankcase Oil Sump plus the capacity of factory installed oil fil-
ters and other filters added to the lubrication system. Enter the
value for the capacity of the Total Lubrication System in this
row.
403C-07 Engine
Table 10
403C-07 Engine
Refill Capacities
Compartment or System
Minimum Maximum
Crankcase Oil Sump
(1)
2.35 L
(2.5 qt)
3.05 L
(3.2 qt)
Total Lubrication System
(2)
(continued)
(Table 10, contd)
(1)
These values are the approximate capacities for the crankcase
oil sump which includes the standard factory installed oil filters.
Engines with auxiliary oil filters will require additional oil. Refer
to the OEM specifications for the capacity of the auxiliary oil
filter.
(2)
The Total Lubrication System includes the capacity for the
Crankcase Oil Sump plus the capacity of factory installed oil fil-
ters and other filters added to the lubrication system. Enter the
value for the capacity of the Total Lubrication System in this
row.
403C-11 Engine
Table 11
403C-11 Engine
Refill Capacities
Compartment or System
Minimum Maximum
Crankcase Oil Sump
(1)
3.4 L
(3.6 qt)
4.9 L
(5.2 qt)
Total Lubrication System
(2)
(1)
These values are the approximate capacities for the crankcase
oil sump which includes the standard factory installed oil filters.
Engines with auxiliary oil filters will require additional oil. Refer
to the OEM specifications for the capacity of the auxiliary oil
filter.
(2)
The Total Lubrication System includes the capacity for the
Crankcase Oil Sump plus the capacity of factory installed oil fil-
ters and other filters added to the lubrication system. Enter the
value for the capacity of the Total Lubrication System in this
row.
403C-15 and 403C-17 Engine
Table 12
403C-15 and 403C-17 Engine
Refill Capacities
Compartment or System
Minimum Maximum
Crankcase Oil Sump
(1)
4.5 L
(4.8 qt)
6 L
(6.3 qt)
Total Lubrication System
(2)
(1)
These values are the approximate capacities for the crankcase
oil sump which includes the standard factory installed oil filters.
Engines with auxiliary oil filters will require additional oil. Refer
to the OEM specifications for the capacity of the auxiliary oil
filter.
(2)
The Total Lubrication System includes the capacity for the
Crankcase Oil Sump plus the capacity of factory installed oil fil-
ters and other filters added to the lubrication system. Enter the
value for the capacity of the Total Lubrication System in this
row.
40
SEBU7992-05
Maintenance Section
Refill Capacities
