(Table 15, contd)
(1)
These values are the approximate capacities for the crankcase
oil sump which includes the standard factory installed oil filters.
Engines with auxiliary oil filters will require more oil. Refer to
the OEM specifications for the capacity of the auxiliary oil filter.
(2)
The Total Lubrication System includes the capacity for the
Crankcase Oil Sump plus the capacity of factory installed oil fil-
ters and other filters added to the lubrication system. Enter the
value for the capacity of the Total Lubrication System in this
row.
404D-15 Engine
Table 16
404D-15 Engine
Refill Capacities
Compartment or System
Minimum Maximum
Crankcase Oil Sump
(1)
3.9 L
(4.1211 qt)
5.6 L
(5.9175 qt)
Total Lubrication System
(2)
(1)
These values are the approximate capacities for the crankcase
oil sump which includes the standard factory installed oil filters.
Engines with auxiliary oil filters will require more oil. Refer to
the OEM specifications for the capacity of the auxiliary oil filter.
(2)
The Total Lubrication System includes the capacity for the
Crankcase Oil Sump plus the capacity of factory installed oil fil-
ters and other filters added to the lubrication system. Enter the
value for the capacity of the Total Lubrication System in this
row.
404D-22, 404D-22T, and 404D-22TA
Engines
Table 17
404D-22,404D-22T, and 404D-22TA Engines
Refill Capacities
Compartment or System
Minimum Maximum
Crankcase Oil Sump
(1)
8.9 L
(9.4 qt)
10.6 L
(11.2 qt)
Total Lubrication System
(2)
(1)
More than one style of sump may be used on these engines.
Use these values to estimate the refill capacity. Use the engine
oil level gauge to fill the engine to the correct oil level. Record
the result in this table. These values are the approximate ca-
pacities for the Crankcase Oil Sump which includes the stand-
ard factory installed oil filters. Engines with auxiliary oil filters
will require more oil. Refer to the OEM specifications for the ca-
pacity of the auxiliary oil filter.
(continued)
(Table 17, contd)
(2)
The Total Lubrication System includes the capacity for the
Crankcase Oil Sump plus the capacity of factory installed oil fil-
ters and other filters added to the lubrication system. Enter the
value for the capacity of the Total Lubrication System in this
row.
Cooling System
To maintain the cooling system, the Total Cooling
System capacity must be known. The approximate
capacity is for the engine cooling system. External
System capacities will vary among applications.
Refer to the OEM specifications for the External
System capacity. This capacity information will be
needed to determine the amount of coolant that is
required for the Total Cooling System.
402D-05 Engine
Table 18
402D-05 Engine
Refill Capacities
Compartment or System
Liters
Quarts
Engine Only
1.1 1.2
External System Per OEM
(1)
Total Cooling System
(2)
(1)
The External System includes a radiator or an expansion tank
with the following components: heat exchanger and piping. Re-
fer to the OEM specifications. Enter the value for the capacity
of the External System in this row.
(2)
The Total Cooling System capacity includes the capacity of the
Engine plus the External System. Enter the value for the ca-
pacity of the Total Cooling System in this row.
403D-07 Engine
Table 19
403D-07 Engine
Refill Capacities
Compartment or System
Liters
Quarts
Engine Only
1.2 1.3
External System Per OEM
(1)
Total Cooling System
(2)
(1)
The External System includes a radiator or an expansion tank
with the following components: heat exchanger and piping. Re-
fer to the OEM specifications. Enter the value for the capacity
of the External System in this row.
(2)
The Total Cooling System capacity includes the capacity of the
Engine plus the External System. Enter the value for the ca-
pacity of the Total Cooling System in this row.
