Warning: This product contains small items that could be a choking hazard if swallowed.Before
starting assembly, verify all parts are included and undamaged. Do not use damaged or defective parts.
lf you require replacement parts, please contact our customer service at
support@perlegear.com.
• Please Note: Not all hardware included in this package will be used.
Tools Needed (Not lncluded)
Supplied Parts and Hardware
Supplied Parts and Hardware for Step 1
02 x 2 03 x 2
Extender Brackets
Supplied Parts and Hardware for Step 2
Note: The washers and spacers are shown in accordance with the actual size.
Bolt
M6 x 12mm
G
M6 Nut
H
x 8
x 8
Faceplate
01A x 1
1/2” (13mm)
Socket Wrench
04
Washers
[If necessary]
05
Spacers
[If necessary]
[B1] x 4
M4 / M5
[B2] x 4
M6 / M8
[F1] x 8
L2.5mm
[F2] x 4
L10mm
[F3] x 4
L22mm
Tools Needed for Wood Stud Installation
Tools Needed for Solid Concrete,
Concrete Block and Brick Walls Installation
Tape Measure Pencil Electric Drill
5/32" (4mm)
Wood Drill Bit
3/8” (10mm)
Concrete Drill Bit
7/16” (11mm)
Socket Wrench
Phillips
Screwdriver
Hammer
Stud Finder Awl
OR
