TV Bolts
06
[Only one bolt fits your TV]
Note: The bolts are shown in actual size.
Wall Anchor
φ10mm
x 4
A2
This anchor is for
concrete or brick walls
ONLY. DO NOT use them
in drywall or wood studs.
CAUTION!
Supplied Parts and Hardware for Step 3
Note: The lag screw is shown in actual size.
Lag Screw
ST1/4 x 2-3/4”
x 4
A1
Arm Assembly / Wall Plate
01B x 1
Level
07 x 1
M6
M4
M8
M4 x 12mm
[C1] x 4
M6 x 15mm
[D1] x 4
M8 x 50mm
[E2] x 4
M8 x 25mm
[E1] x 4
M6 x 35mm
[D2] x 4
M4 x 30mm
[C2] x 4
01 02 03 04 05 06 07 08 09 10 11
12 13 14 15 16 17 18 19 20 21 22
23 24 25 26 27 28 29 30 31 32 33
34 35 36 37 38 39 40 41 42 43 44
45 46 47 48 49 50 51 52 53 54 55
To Next Page
