Option A (For Flat Back TV)
TV7
TV1/TV3/TV5
04
TV7
TV8/TV9
TV2/TV4/TV6
04
(if needed)
(if needed)
Option B (For Round Back TV)
Alternate
Spacer
Setups
UP
CAUTION: Ensure the faceplate
[04] is EQUALLY CENTERED on
your TV and securely fastened in
place.
Please note: The bolt hole
locations on your TV may vary in
accordance of the manufacturers
design of the TV. We are only
illustrating possible locations of
the bolt holes.
01 02 03 04 05 06 07 08 09
