3/8 in.(10mm)
Socket Wrench
(Not included)
Tilt Adjustment
1. Loosen four tilt bolts [T].
2. Adjust TV to your desired tilt angle.
3. Retighten four tilt bolts [T] to fix the tilt angle.
If needed, the TV can be levelled
Level Adjustment
06
1. Loosen the four bolts [B1].
2. Level your TV.
3. Retighten four bolts [B1] to hold TV in place.
B1
10
Tilt adjustment
T
Loosen Tighten
Note: Please do not over-tighten
or over-loosen the bolts
Note: Please do not over-tighten
or over-loosen the bolts
